Part Number: IS200EGDMH1A

Manufacturer: GE

Condition: Brand New

The IS200EGDMH1A is a PCB component for the Mark VI series from GE.  The Mark VI is the fifth gas/steam turbine management series released by GE under the Speedtronic umbrella.

The IS200EGDMH1A works with an EXAM card to detect any field ground leakage current anywhere in the field circuit of the generator to ground, on both the ac and the dc side.  Simplex systems use a single EGDM board. Redundant systems need three. The three boards are then configured as a Controller <C1> that receives information from the active DSPX, a Master 1 <M1> which provides the drive signal to the Attenuator Module’s sense resistor, and a Master 2 <M2.>    GE publication GEH-6632 (EX 2100 Excitation Control User’s Guide) has more information on these boards and their setup.

The IS200EGDMH1A is designed with a wide front panel.  The IS200EGDMH1A is a double-slot board. The front panel includes the manufacturer’s logo, the board number, and several warning lights.

The IS200EGDMH1A is built with two backplane connectors.  It has seven high voltage capacitors that are placed in two lines.  The board has one relay, one CPU socket, and multiple integrated circuits.  The board is built with metal film resistors as well as resistors of other material.
