ABB 3HAC025314-001

Sales Manager :Yuki  / Phone: +8617359287459

Email: sales15@amikon.cn  / Skype:+8617359287459

ABB 3HAC025314-001

Technical Information:
Part of the Dresspack Toolkit.
Valid for Silver Line, Orange Line,
IRB 6400R, 6600, 6650, 6650S, 7600, 6640, 6620

 AC 800M Controller – Key Features

• Modularity, allowing for step-by-step expansion.
• Simple DIN-rail attachment/detachment procedures, using a unique slide and
lock mechanism.
• Fast, simple troubleshooting procedures available via unit/channel LEDs.
• IP20 Class protection with no requirement for enclosures.
• Allows for the use of low-cost, sealed enclosures due to extremely low unit
heat dissipation, even at an ambient temperature of 40 C (104 F) outside the
enclosure.
• All units are fully EMC certified.
• Connection of up to 192 I/O signals, via Electrical ModuleBus, is available.
• Connection of up to 1344 I/O signals, via Optical ModuleBus, is available.
• Connection of S100 I/O is available.
• Connection of Satt I/O is available.
• Allows connecting a large number of I/Os, via PROFIBUS DP.
• Connection to FOUNDATION Fieldbus High Speed Ethernet (FF HSE).
• Connection to Modbus TCP.
• Connection to IEC 61850.
• Connection to Advant Fieldbus 100.
• Connection to MOD5-to-MOD5.
• Connection to PROFINET IO.
• Connection to EtherNet/IP.
• Allows connecting custom protocols of a large amount of Serial
communication RS-232C ports.
• Connection to MasterBus 300 Networks.
• Connection to INSUM via Gateway (Ethernet/LON).
• Connection to ABB Drives is available, over DriveBus and ModuleBus
• Built-in battery backup of memory (except for PM891 that uses external
battery backup only).
• External battery backup.
• CPU Redundancy (PM861/PM864/PM865/PM866/PM891).
• Redundant/sectioned CEX-Bus using a pair of BC810.
• Safety Integrity Level 2 certified controller using PM865/SM810/SM811.
• Safety Integrity Level 3 certified controller using PM865/SM811
• Support for hot swap of CEX-Bus units.
