 CEX-Bus Terminator

TB807 ModuleBus Terminator Plug
The Terminator plug must always be mounted on the last I/O unit of the ModuleBus. If
no units are used on the ModuleBus, no bus termination is required. No ModuleBus
termination is required in redundant CPU configuration.

A.41.4 TB852 RCU Link Terminator Plug
The TB852 RCU Link Terminator Plug is required when the

PM857/PM858/PM861/PM862/PM863/PM864/PM865/PM866/PM867 processor unit operates

in single configuration.

A.41.5 TB853 RCU Control Link Terminator Plug
The TB853 RCU Control Link Terminator Plug is required when the PM891 processor unit

operates in single configuration. This is plugged to the RCU Control port at the top of the

PM891 unit.

TK850 CEX-Bus Extension Cable
A 0.7 m (2.3 ft.) extension cable, complete with connector (type DB25P-metal housing)

provides connectivity to Communication Interface units between adjacent DIN-rails. It is

always used in redundant CPU configuration for connecting the CEX-Bus between the two

processor units.

A.41.7 TK851 RCU Link Cable
The Redundant Control Unit Link Cable is used to transfer log data from the Primary CPU

to the Backup CPU, and to exchange status and control information between the Primary

and Backup CPUs. The RCU Link uses 68-pole connectors, one of which is labeled “UPPER”.

The CPU connected to this connector will be defined as the upper CPU in the Control Builder

and Operator Station.The RCU Link Cable is also used as interconnection cable between two BC810.
