2711-T14C16 Touchscreen ▏

2711-T14C16 14-inch Color CRT touchscreen

  • Item NO.:

    2711T14C16
  • Payment:

    T/T
  • Product Origin:

    United State
  • Shipping Port:

    Xiamen, China
  • Lead Time:

    In Stock
Inquiry now
Product Detail

Product  2711-T14C16 Touchscreen

Origin: USA

Brand new with one year warranty



Product overview

brand :  Allen Bradley

The 2711-T14C16 is a Series B PanelView standard 1400 terminal that features a 14-inch Color CRT touchscreen. This terminal does not have any keypad input.

The screen is made up of 24 columns and 16 rows that are filled up with 384 touch cells, with each touch cell measuring 37 x 33 pixels in size.

 It also has an 800 x 600-pixel resolution. Status indicators are available with the 2711-T14C16 terminal and these allow users to monitor the current state of the entire terminal.

It comes with an RS-232 (DF1) communication port and an RS-232 printer port that also has a download feature. It also has a total application flash memory of 1008 KB.

The terminal requires a NEMA Type 12/13 or 4x enclosure that is for indoor use only. It measures 13.97 x 17.37 x 15.53 inches and weighs 43.2 pounds.


This terminal has an operating vibration of 1g at up to 2000 Hertz, an operating vibration of 15g, and a non-operating vibration of 30g. It also has a storage temperature

between -40 and 185 degrees Fahrenheit and an operating temperature between 32 and 131 degrees Fahrenheit. The terminal has a maximum power consumption of 200 VA and supply

voltage limits of 43 to 63 Hertz and 85 to 264 Volts AC. Its relative humidity is 5 to 95% that is non-condensing at 32 to 131 degrees Fahrenheit and it also has heat dissipation of 78 W or 264 BTU/hour.


Part Number: 2711-T14C16

Power Type: AC

Supply Voltage Limit: 85-264 Volts; 43-63 Hertz

Power Consumption: 200 VA max

Comm Port: RS-232 (DF1)

Total Application Flash Memory: 1008 Kbytes

Operating Shock: 15 g

Non-Operating Shock: 30 g

Operating Temperature: 32-131 F (0-55 C)

Dimensions: 13.97 x 17.37 x 15.53 in (355 x 441 x 394 mm)

Display Dimensions: 10.0 x 7.5 in (255 x 191 mm)

Weight: 43.2 lbs (19.6 kg)

Method of Input: Touchscreen



Direct contact
