1762-IR4 Resistance Module

Part number: 1762-IR4 Resistance Module

Condition: Brand new and Original

Origin: USA.

PACKING: Packing is factory sealed

SHIPMENT: by air express ( DHL/Fedex/TNT/UPS )

Warranty : Fully serviced, 1 year warranty

Lead time: 1-2 working days

Call For Best Price

Contact: Leonia  Huang                      Email: sales11@amikon.cn

Tel/whatsapp:+86-18030175807         Skype: live:2435aba439730baa

Technical Specifications

1762-IR4 1R4 Ser A MicroLogix 1200 RTD Resistance Input Module 4Ch

Type of electric connection: Screw connection
Open-circuit detection time: 6 ms
Channel to channel isolation: ±10V DC
Input type: 604 Ω Nickel-Iron 518
Bus current draw: 50 mA @ 24V DC, maximum
Fast transient burst: IEC1000-4-4: 2kV, 5 kHz
Update time: Input filter and configuration dependent (typical)
Normal mode rejection ratio: 70 dB minimum @ 60 Hz with the 10 or 60 Hz filter selected
Conducted immunity: IEC 1000-4-6: 10 V/m, 80...1000 MHz, 80% amplitude modulation, +900 MHz keyed carrier
Radiated immunity: IEC 61000-4-3: 10 V/m, 80...1000 MHz, 80% amplitude modulation, +900 MHz keyed carrier
Typical accuracy: At 25 ° C (77 °F) ambient with module operating temperature at 25 °C (77 °F)
Resolution: Input filter and configuration dependent
Suitable for safety functions: No
Overload at input terminals: Maximum @ ±35V DC continuous
Surge immunity: IEC1000-4-5: 1kV galvanic gun
Module power LED ON: indicates power is applied
Excitation current source: 0.5 mA and 1.0 mA selectable per channel
Cable impedance: Maximum @ 25 Ω (operating with >25 Ω will reduce accuracy)
Power supply distance rating 6 (the module may not be more than 6 modules away from the system power supply)
Heat dissipation: 1.5 total Watts (the Watts per point, plus the minimum Watts, with all points enabled)
Input channel configuration: Via configuration software screen or the user program (by writing a unique bit pattern into the module’s configuration file)
Operating temperature: -20 °C
ESD immunity IEC1000-4-2: 4kV contact, 8kV air, 4kV indirect
Operating altitude: 2000 m
Storage temperature: -40 °C
Operating humidity: 5...95% noncondensing

Input Specifications
A/D converter type: Delta-Sigma
Common mode rejection: >110 dB at 60 Hz (with 10 or 60 Hz filter)
Input impedance: >10 MΩ
Channel diagnostics: Over or under range or open circuit condition by bit reporting for analog inputs

Output Specifications
Non-linearity: ±0.05% (in percent full scale)
Typical overall accuracy: ±0.5 °C (°F) for Pt 385

General Specifications
Repeatability: ±0.2 ohm for other resistances
Input and output group to system isolation: 30V AC/30V DC working voltage type test: 500V AC or 707V DC for 1 minute
Vibration Operating: 10...500 Hz, 5 G, 0.030 inch @ maximum peak-to-peak
Shock Operating: 30 G

Shipping weight: approx 260 g
Recommended cable Belden 8761 (shielded)
Height 90 mm
Width 40 mm
Depth 87 mm
